OSG Carbide End Mill WX4 Blade Corner R Short Powerful Heavy Cutting 8XR2 301638 WX-CR-PHS-8XR2 1 Piece

Catalog number: WX-CR-PHS-8XR2 Features: ●This is a strong twist radius end mill that combines high chip removal and cutting edge rigidity. In addition to normal 2D machining, it supports a wide range of cutter paths such as ramping and profile machining. Applications: ●Cutting materials: carbon steel, alloy steel, tool steel (up to 40HRC), pre-hardened steel, hardened steel (up to 45HRC), cast iron, ductile cast iron (up to 350HB), stainless steel, titanium alloy, heat-resistant alloy. Specifications: ●Blade diameter (mm): 8 ●Corner radius (mm): 2 ●Blade length (mm): 19 ●Total length (mm): 80 ●Shank diameter (mm): 8 ●Number of blades (pieces): 4 ●Surface treatment: WX coating ●Number of blades: 4 ●Twist angle 45° Material/Finish: ●Carbide
