パナソニック（株）エレクトリックワークス社
Panasonic Circuit Breaker BBW-60 3P3 BBW3302 1 piece
Panasonic Circuit Breaker BBW-60 3P3 BBW3302 1 piece
Regular price
¥7,550
Regular price
Sale price
¥7,550
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: BBW3302 Features: ● Used for overload, short circuit and motor protection. Applications: ● For panels. (Terminal cover sold separately) Specifications: ● Number of poles and elements: 3P3E ● Rating: 30A ● Width (mm): 70 ● Length (mm): 52 ● Height (mm): 96 ● Compatible wire: φ1.6-2.6, 2-14m [M2] ● Rated insulation voltage: AC500V ● Insulation resistance: 5MΩ or more ● Withstand voltage performance: 2500V x 1 minute
