PISCO Tube Fitting Brass Union Tee Without Cover KE4-1 1 pc

Catalog number: KE4-1 Features: ●The release ring is made of brass in addition to the main body, so it has excellent flame retardancy and spatter resistance. ●This is a type without a cover. Specifications: ●Applicable tube outer diameter D (mm): 4 x 4 x 4 ●Maximum operating pressure (MPa): 1.0 ●Fluid used: air, water (conditions apply), heat transfer oil (conditions apply) ●Operating temperature range: 0 to 100°C (no freezing) ●Maximum operating pressure: 1.0MPa ●Vacuum pressure used: -100kPa Material/Finish: ●Main body: Brass + electroless nickel plating Caution: ●If the fluid used is heat transfer oil, the heat transfer oil may adhere to the release ring and guide ring and solidify, causing a sliding malfunction and hindering the release or lock function. When using, make sure that there is no heat transfer oil on the release ring or guide ring. Also, when reconnecting the tube, make sure that the tube does not come loose before using.
