PISCO Vacuum Generator, Solenoid Valve Direct Mount Type, Elbow, Atmospheric Release, VHH07601, 1 pc

Catalog number: VHH07601 Features: ●Compressed air can be converted into a vacuum, and when combined with a vacuum pad, it can be used to transport workpieces. Applications: ●For suction and transport of workpieces. Specifications: ●Applicable tube outer diameter D (mm): 6 (vacuum port) ●Connection diameter: R1/8 (air supply port) ●Nozzle diameter (mm): 0.7 ●Usable fluid: air ●High vacuum type ●Usable temperature range: 0 to 60°C (no freezing) ●Usable pressure range: 0.15 to 0.7 MPa ●Rated supply pressure: 0.5 MPa Materials/Finish: ●Metal parts: brass + electroless nickel plating ●Resin parts: PBT ●Seal rubber: NBR ●Element: PVF
