Catalog number: SF-45MT-2VP Features: ●Uses a totally enclosed motor with excellent durability and safety. ●Can be used with a main power source (three-phase 200V), making it economical for long-term use. ●Two-speed system with strong and weak airflow. Applications: ●Ventilation and air circulation in factories and warehouses. Specifications: ● Power supply (V): Three-phase 200 ● Power consumption (W) (50/60Hz): 105/155 ● Blade diameter (cm): 45 ● Power cord length (m): 2 (without plug) ● Blade material: Resin ● Replacement blade: SF-45M-PF ● Oscillation: Yes ● Airflow adjustment: 2-stage (strong/weak) ● Maximum airflow (m³/min) (50Hz): 215 ● Maximum airflow (m³/min) (60Hz): 245 ● Standard power consumption charge (50Hz): 1.4 yen/h ● Standard power consumption charge (60Hz): 2.1 yen/h ● Standard power consumption charge (50/60Hz): 1.4/2.1 yen/h ● Power cord length: 2m (without plug) ● Oscillation angle: 87° ● Blades: 4 (made of resin) Material/Finish: ● Blades: Resin Note: If using in an environment where high frequency waves are generated or oil is floating, please use aluminum blades. The blades may crack due to interference from high frequency waves or chemical reactions of the resin caused by the type of oil.
