TAIYO Filter Regulator (with bracket, D-type pressure gauge) SFR3-08-BD 1 piece

Catalog number: SFR3-08-BD Features: ●Adjusts air pressure and removes water droplets and debris from the air to supply clean air. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 1 ●Set pressure (MPa): 0.05-0.85 ●Connection diameter: Rc1/4 ●Total length (mm): 146 ●Total width (mm): 45 ●Pressure gauge: D-type ●Drain storage volume (cm3): 9.5 ●Operating temperature range: -5 to +60°C (but do not freeze) ●Filter element (μm): 5 ●Drain storage volume (cm3): 9.5 ●Drain discharge method: Manual ●Used fluid: Air Set contents/accessories: ●Bracket ●D-type pressure gauge Note: ●The manual drain automatically discharges drain when the pressure falls below 0.05MPa. ●The D-type pressure gauge will be shipped without being assembled to the main unit.
