TRIENS Air Hose Reel Inner Diameter 6.5mm x 10m Orange SHS-210A-OR 1 unit

Catalog number: SHS-210A-OR Features: ● Fittings make hose replacement easy. ● Standard model most commonly used in automobile repair shops. ● Small and lightweight, does not take up much space. ● Uses a mounting base that is easy to attach and detach. ● Can be swiveled as needed. ● A plastic protective spring is used at the end of the hose to reduce hose damage. ● Standard model most commonly used in automobile repair shops in Japan. ● Products with "FA" at the end of the part number are brake type. Applications: ● For supplying air when using pneumatic tools. ● Various assembly lines, maintenance factories, etc. Specifications: ● Hose inner diameter x outer diameter (mm): 6.5 x 10 ● Total hose length (m): 10 ● Primary installation side: Male swivel R1/4 ● Secondary installation side: G1/4 female thread ● Primary hose length (m): 0.8 ● Secondary hose length (m): 10 ● Maximum operating pressure (MPa): 1.4 ● Operating pressure (MPa): 1.4 ● Width (mm): 290 ● Depth (mm): 152 ● Height (mm): 314 ● Outer diameter (mm): 10 ● Installation type: Hanging/wall mounted ● Inner diameter (mm): 6.5 ● Compatible tube outer diameter (mm): 10 ● Color: Orange ● Hose material: Urethane ● Operating pressure: 1.4MPa ● Total hose length: 10m ● Primary side hose length (m): 0.8 ● Body dimensions (mm): 314 x 290 x 152 ● Body weight (kg): 3.5 ● Primary installation side: Male swivel R1/4 ● Secondary installation side: G1/4 female thread Material/Finish: * Hose: Polyurethane * Body cover: Resin Set contents/Accessories: * Mounting base set * Female coupler Note: * Products with "FA" at the end of the part number are brake type.
