TRIENS Spark-resistant soft hose reel, inner diameter 6.5 mm x 13 m, SHS-213SB, 1 unit

Catalogue number: SHS-213SB Features: *Newly designed hose that maintains its softness even at low temperatures and is less likely to curl. *Spark-resistant hose. *Hose with improved slipperiness. *Coupling specifications allow for easy hose replacement. *Resin protective spring at hose tip reduces hose damage. *Can be swiveled as needed. Applications: *For supplying air when using pneumatic tools. *Various assembly lines, maintenance factories, etc. *For work environments where sparks fly. Specifications: ● Hose inner diameter x outer diameter (mm): 6.5 x 10 ● Total hose length (m): 13 ● Primary mounting side: Male free R1/4 ● Secondary mounting side: G1/4 female thread ● Primary hose length (m): 0.8 ● Secondary hose length (m): 13 ● Maximum operating pressure (MPa): 1.4 ● Operating pressure (MPa): 1.4 ● Width (mm): 290 ● Depth (mm): 152 ● Height (mm): 314 ● Outer diameter (mm): 10.0 ● Installation type: Hanging / wall mounting ● Inner diameter (mm): 6.5 ● Compatible tube outer diameter (mm): 10 ● Color: Gray ● Hose material: Flame retardant polyvinyl chloride (hose outer layer) ● Hose color: Black ● Capacity (kg): 3.8 Material / Finish: ● Hose: Flame retardant polyvinyl chloride (hose outer layer) ● Body cover: Resin Set contents / Accessories: ● Complete installation base ● Female coupler Note: ●SHS-210SFB is a brake type.
