TRUSCO Aluminum Level Box Type 230mm Horizontal/Vertical/45° TL-230 1 pc

Catalog number: TL-230 Features: ● A semi-cylindrical vial that appears larger due to the lens effect. (Horizontal) ● 45° measurement possible. ● Box-shaped frame with scale graduations. ● End cover is flat, so it can be placed firmly against a wall for measurement. Applications: ● For measuring inclination. Specifications: ● Length (mm): 230 ● Height (mm): 50.5 ● Thickness (mm): 19 ● Magnet: None ● Accuracy: Within ±1.5mm/m = ±0.0859° ● Sensitivity: 0.5mm/m = 0.0286° Material/Finish: ● Body: Aluminum ● Vial: Acrylic resin (PMMA)
