TRUSCO All Anchor T-Type Steel 5X30 10 Pieces (Concrete Anchor/Core Rod Drive-in Type) T-530BT 1 PK

Catalog number: T-530BT Features: ● An anchor ideal for installation in places where removal is not required. ● Installation is as simple as driving in the core rod, so you can see when installation is complete at a glance. ● Can be installed directly on top of the object being attached. Applications: ● Installation of blinds. ● Installation of lighting fixtures, wiring, piping, hanging hardware, etc. Specifications: ● Maximum thickness of object to be attached (mm): 10 ● Pilot hole diameter (mm): 5.4 ● Maximum tensile load (kN): 3.4 ● Outer diameter (mm): 5 ● Head diameter dk (mm): 9 ● Neck length (mm): 30 ● Packed Material/Finish: ● Steel ● Surface treatment: Trivalent chromate treatment Note: ● The maximum tensile load is the value when the concrete strength Fc = 21N/[[MM2]].
