Catalogue number: TP-SR02 Features: ● The main body is made of resin, making it a lightweight and inexpensive silencer. ● Ideal for eliminating exhaust noise from air. Specifications: ● Volume reduction (dB): 25 ● Effective cross-sectional area (mm2): 40 ● Connection diameter: R1/4 ● Overall length (mm): 62.5 ● Operating pressure (MPa): 1 ● Fluid used: Air ● Operating pressure: 1MPa ● Fluid temperature: 5 to 60°C Materials/Finish: ● Body: Polyacetal resin ● Element: Filter lens
