TRUSCO Spray Gun Set Suction Type Nozzle Diameter Φ2.0 SSG-20S 1 S

Catalog number: SSG-20S Features: ● A gun and cup set that can be used immediately. ● It reduces the scattering of paint mist and improves the coating efficiency, while improving performance quality and further improving workability. Applications: ● Painting of small items, medium-sized items, etc. Specifications: ● Nozzle diameter (mm): 2 ● Required compressor (kW): 0.75 to 1.5 ● Air consumption (L/min): 170 ● Pattern opening (mm): 210 ● Atomization stage: General purpose ● Air attachment port: G1/4 ● Cup attachment port: G1/4 ● Cup capacity (cc): 1000 ● Paint supply method: Suction type ● Suction type Material/Finish: ● Body: Aluminum die-cast ● Liquid contact part: Stainless steel (SUS303), brass, aluminum die-cast ● Cup: Aluminum die-cast
