TRUSCO Rod End, Oil-Free, 8mm Thread (2 Pieces) CHSL8, 1 Box

Catalogue number: CHSL8 Features: ● Oil-free type with synthetic resin with excellent self-lubricating properties bonded to the race surface of the ball. Applications: ● Various conveying machine parts. ● Various machine tool parts. ● FA equipment. ● Packaging machine parts. ● Textile machine parts. ● Agricultural machinery parts. ● Robot parts. Specifications: ● Shaft diameter (mm): 8 ● Overall width (mm): 24 ● Center distance (mm): 36 ● Overall height (mm): 48 ● Thread dimensions: M8 x 1.25 ● Basic dynamic load rating (kN): 12.90 ● Oil-free type ● Operating temperature range: -30 to 150°C ● Female thread type (left-handed thread) Material/Finish: ● Body: Steel ● Race: Self-lubricating synthetic resin ● Ball: High carbon chromium bearing steel
