TRUSCO Relay Terminal Block 300V 15A 4P TOTB-406NA-4P 1 pc

Catalog number: TOTB-406NA-4P Features: ●Terminal block for relay connection of electric wires. ●Comes with a one-touch cover. Specifications: ●Color: Black ●Number of poles: 4 ●Length (mm): 58 ●Width (mm): 24 ●Height (mm): 16.5 ●Type: For relay ●Rating: 15A ●Rated insulation voltage (V): 300 ●Mounting pitch (mm): 10 ●Screw size: M3.5 ●Standard: UL94V-0 ●2-wire connection possible ●Comes with one-touch cover ●Operating temperature range: -40℃ to 90℃ ●Insulation resistance: DC500V 1000MΩ or more ●Withstand voltage: AC2500V 1 minute ●Temperature rise: 30℃ or less Material/Finish: ●Body: Polybutylene terephthalate (Flame retardant grade UL94V-0) ●Cover: Polycarbonate (Flame retardant grade UL94V-0)
