TRUSCO Plug-in Wire Connector, 8 poles (4 pieces) T-QL-8 1 PK

Catalog number: T-QL-8 Features: ● Unique two-point contact spring structure. ● Wiring can be visually confirmed through the transparent cover. ● Compliant with JIS C2813 (plug-in type electric wire connector for indoor wiring). (Certified inspection agency: <PS> E JET) Applications: ● For connecting stripped wires together. Specifications: ● Number of poles: 8 ● Color: Green transparent ● Rated current: 20A ● Length (mm): 20.5 ● Width (mm): 39.2 ● Height (mm): 9.1 ● Rated voltage (V): 300 ● Rated voltage: 300V ● Operating temperature range: -40 to 80°C ● Compatible wire (copper/single wire): φ1.6mm, φ2.0mm ● Operating temperature range: -40 to 80°C Materials/Finish: ● Spring: Stainless steel (SUS301) ● Conductive plate: Oxygen-free copper (C1020)/tin-plated ● Housing: Polycarbonate (PC)
