Catalog number: TB-5.5 Features: ●There is a wire stopper in the tube. Uses: ●Insert wires from both sides of the sleeve, and butt the wires together at the protrusions (stoppers) inside the sleeve for crimping and connection. Specifications: ●Wire clamping range Stranded wire (mm2): 2.63-6.64 ●Wire clamping range Solid wire (mm): 1.82-2.89 ●Wire clamping range AWG: 12-10 ●Total length (mm): 15 ●Inner dimensions (mm): 3.5 ●JIS standard product: ○ ●Color: Silver ●Compatible tools: Tools for bare crimp terminals and sleeves ●External dimensions (mm): 5.4 ●L (mm): 15.0 ●d (mm): 3.4 ●JIS C2806 compliant (except P-1.25) ●B type Material/Finish: ●Oxygen-free copper (C1020)/Electrolytic tin plating
