Catalog number: TP-25TOGB-8 Features: ●A compact unit that integrates the functions of an air filter, regulator, and lubricator on the same axis by using a double bottle. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 0.05 to 1.0 ●Processing air flow rate (m3/min): 0.7 ●Connection diameter: Rc1/4 ●Oil storage capacity (cm3): 50 ●Total length (mm): 202.5 ●Set pressure (MPa): 0.05 to 0.85 ●Fluid used: Air ●Fluid temperature (℃): 5 to 60 ●Fluid temperature: 5 to 60℃ ●Drain discharge method: Manual (however, drains automatically when pressure falls below 0.05MPa) ●Oil used: Turbine oil type 1 (equivalent to ISO VG#32) ●Comes with pressure gauge and bracket
