Catalog number: BG-1070 Features: ●Torque-controlled construction and a large three-sided wedge provide reliable strength. ●Since the screw diameter and pilot hole diameter are the same, construction can be performed from above the object being attached. Applications: ●Electrical installation and piping work, heating and cooling duct work, elevator work, handrail installation, etc. Specifications: ●Screw size: M10 ●Total length (mm): 70 ●Maximum tensile load (kN): 14.7 ●Embedded depth (mm): 52 ●Pilot hole diameter (mm): 10.0 ●Boxed Material/Finish: ●Steel Notes: ●The maximum tensile load is the value when the concrete strength is FC=21N/[MM2] ●The maximum tensile load is the value when the concrete strength is Fc21N/[MM2].
