UNIKA Rooty Anchor SC Type (Stainless Steel) SC-2013 SC-2013 10 Pieces

Catalog number: SC-2013 Features: ●Simple work of just driving in the pins ensures reliable installation. ●Made of all stainless steel, resistant to rust. ●Can be widely installed in humid places. ●Simple work of just driving in the pins ensures reliable installation. ●Just by looking at the pins, you can be sure that the pins have been driven in. Applications: ●Architectural, electrical, sanitation, heating and cooling construction, sign and chair installation, machine installation, etc. Specifications: ●Screw size: M20 ●Total length (mm): 130 ●Screw length (mm): 50 ●Maximum thickness of object to be attached (mm): 25 ●Drill hole diameter (mm): 21.5 ●Maximum tensile load (kN): 52.7 ●Embedding depth (mm): 80 ●Boxed Material/Finish: ●Stainless steel Note: ●The maximum tensile load is the value when the concrete strength is Fc21N/[MM2].
