UNIKA Resin A SE type (sealed capsule type) SE-20 SE-20 1 bottle

Catalogue number: SE-20 Features: *An adhesive anchor with excellent earthquake resistance. *Suitable for application to wet base materials. *Uses highly alkali-resistant vinyl ester resin, allowing for long-term storage before application. Applications: *Foundation work for steel frames, etc. *Road construction. *Tunnel construction. *Installation work for vibrating machinery, etc. Specifications: ●Outer diameter (mm): 21.5 ●Total length (mm): 175 ●Capacity (cm3): 53.0 ●Capacity (ml): 53 ●Bolt used (irregular steel bar): M20, W3/4 (D19) ●Drill diameter (irregular steel bar) (mm): 25.0 (25.0) ●Drilling depth (mm): 180 ●Maximum tensile load (kN): 170.1 ●Long-term allowable tensile load (kN): 25.1 ●Short-term allowable tensile load (kN): 50.2 ●Rotational/impact type Material/Finish: ●Main agent: Vinyl ester resin Note: ●The maximum tensile load is the value for bolts (excluding irregular shapes) when the concrete strength FC = 21N/mm2.
