Einz Tool Changer Tool Side OX-SBSI 1 pc

Catalog number: OX-SBSI Features: ● Equipped with a unique release mechanism. (Patent No. 4126074) ● Built-in fail-safe mechanism. ● Robot hand can be easily replaced in a short time. ● Air option can be added. Specifications: ● Type: Tool side ● Width (mm): 54 ● Depth (mm): 83 ● Height (mm): 20.5 ● Weight capacity (kg): Up to 5 ● Pull-in force/push-out force (N): 1000/280 ● Weight capacity: Up to 5kg ● Air pressure used: 0.5-0.7MPa ● Thickness when connected: 29mm ● Connector: D-SUB connector & probe connector ● Electrical contact: 9 cores x 1 (2A DC24V Max) ● Pipe connection: 6 circuits (M5) ● Position repeatability: ±0.02mm Material/Finish: ● Super duralumin
