Catalog number: AD-1 Features: ● Equipped with a safety device against overload (overcurrent, overheating) and a circuit breaker that can be manually reset. ● The head can be replaced. ● The head (motor) can be easily attached and detached. ● By purchasing various motors sold separately, the electric type can be replaced with an air motor type. ● A plastic cap is standard equipped on the tip of the gun nozzle to prevent contamination. ● Uses a nozzle that is easy to grip. ● The grip is made of plastic and curved, minimizing strain on the hand. (Tip diameter φ19)) ● Waterproof standard protection class IP24 means it is not affected by water splashes from any direction. Applications: ● For dividing and transferring AdBlue (urea water). Specifications: ●Discharge volume (L/min): 30 ●Total length (mm): 5 ●Lift height (m): 5 ●Power supply (V): AC100 ●Type: For plastic drums ●Width (mm): 171 ●Depth (mm): 97 ●Height (mm): 1033 ●Power cord length (m): 2.9 ●PSE (Electrical Appliance and Material Safety Act) compliant ●Ad-2 hose: (reinforced PVC φ25 x 3m) ●Ad-1 hose: (reinforced PVC φ25 x 2m) ●Frequency: 50/60Hz ●Power consumption: 145W ●Power cord length: 2.9m ●Usable viscosity: 100cP or less ●Plastic drum (can be installed with Kodama Resin or Sanko drums *separate adapter required) Material/Finish: ●Liquid contact parts: PP, SUS316, PTFE, ETFE ●Gasket: FKM Note: ●A screwdriver is required to replace the head. ●If it is made of Kodama resin, please purchase G2-A (order code: 244-4748) or if it is made of Sanko resin, please purchase G2-B.
