Aluminum electrolytic capacitor 100μF 100V dc 1 bag (5 pieces) UVK2A101MPD 1 bag (5 pieces)

Aluminum electrolytic capacitor, VK series, 85°C Small aluminum electrolytic capacitor 85°C 2000 hours (rated) PET sleeve (non-PVC) Lead-free plating on terminals Operating temperature range: -40 → +85°C, -25 → +85°C (rated voltage: 450 V) Capacitance tolerance: ±20% Quantity: 1 bag (5 pieces) Voltage: 100V dc Mounting Type: Through Hole Dimensions: 10 (Dia.) x 16mm Height: 16mm Operating temperature Min: -40°C Lead pitch: 5mm Lead diameter: 0.6mm Series: VK Diameter: 10mm Ripple current: 340mA Leakage current: 3 μA, 4 μA Tolerance: ±20% Tolerance (negative): -20% Tolerance (plus): 20% RoHS Compliance Status: Compliant Code: 475-8387
