Aluminum electrolytic capacitor 3300μF 16V dc 1 bag (5 pieces) UHE1C332MHD 1 bag (5 pieces)

Durability: (Varies with rated voltage and case size) Aluminum electrolytic capacitor HE series 105°C Small, low impedance, highly reliable PET sleeve (PVC-free) Lead-free plated terminals Operating temperature range: -40 to +105°C Capacitance tolerance: ±20% Leakage current (2 min): I = 0.01 CV or 3 μA, whichever is greater Quantity: 1 bag (5 pieces) Voltage: 16V dc Mounting Type: Through Hole Dimensions: 12.5 (Dia.) x 35.5mm Height: 35.5mm Operating temperature Min: -40°C Lead pitch: 5mm Lead diameter: 0.8mm Lifespan: 10000h Diameter: 12.5mm Ripple current: 2.88A Leakage current: 3 μA Tolerance: ±20% Tolerance (negative): -20% Tolerance (plus): 20% RoHS Compliance Status: Compliant Code number: 490-9838
