Aluminum electrolytic capacitor 47μF 35V dc 1 bag (5 pieces) UVK1V470MDD 1 bag (5 pieces)

Aluminum electrolytic capacitor, VK series, 85°C Small aluminum electrolytic capacitor 85°C 2000 hours (rated) PET sleeve (non-PVC) Lead-free plating on terminals Operating temperature range: -40 → +85°C, -25 → +85°C (rated voltage: 450 V) Capacitance tolerance: ±20% Quantity: 1 bag (5 pieces) Voltage: 35V dc Mounting Type: Through Hole Dimensions: 5 (Dia.) x 11mm Height: 11mm Operating temperature Min: -40°C Lead pitch: 2mm Lead diameter: 0.5mm Series: VK Diameter: 5mm Ripple current: 130mA Leakage current: 3 μA, 4 μA Tolerance: ±20% Tolerance (negative): -20% Tolerance (plus): 20% RoHS Compliance Status: Compliant Code number: 475-7952
