Aluminum electrolytic capacitor 470μF 10V dc 1 bag (5 pieces) UVK1A471MED 1 bag (5 pieces)

Aluminum electrolytic capacitor, VK series, 85°C Small aluminum electrolytic capacitor 85°C 2000 hours (rated) PET sleeve (non-PVC) Lead-free plating on terminals Operating temperature range: -40 → +85°C, -25 → +85°C (rated voltage: 450 V) Capacitance tolerance: ±20% Quantity: 1 bag (5 pieces) Capacitance: 470μF Mounting Type: Through Hole Dimensions: 6.3 (Dia.) x 11mm Height: 11mm Operating temperature Min: -40°C Lead pitch: 2.5mm Lead diameter: 0.5mm Lifespan: 2000h Diameter: 6.3mm Ripple current: 350mA Leakage current: 3 μA, 4 μA Tolerance: ±20% Tolerance (negative): -20% Tolerance (plus): 20% RoHS Compliance Status: Compliant Code number: 475-7671
