Aluminum electrolytic capacitor 470μF 6.3V dc 1 bag (5 pieces) UPS0J471MPD 1 bag (5 pieces)

Nichicon PS Series Capacitors Nichicon PS Series Aluminum Electrolytic Capacitors are highly reliable polymer capacitors with a lifespan of up to 3000 hours. PS series capacitors feature a wide operating temperature range, high voltage, low impedance, and high ripple current. Features and Benefits: High reliability High ripple current Long life up to 3000 hours Lead-free reflow soldering Low ESR Wide temperature range Miniature size Quantity: 1 bag (5 pieces) Voltage: 6.3V dc Mounting Type: Through Hole Dimensions: 8 (Dia.) x 11.5mm Height: 11.5mm Operating temperature Min: -55°C Lead pitch: 3.5mm Lead diameter: 0.6mm Lifespan: 2000h Diameter: 8mm Ripple current: 410mA Leakage current: 4 μA Tolerance: ±20% Tolerance (negative): -20% Tolerance (plus): 20% RoHS Compliance Status: Compliant Code number: 519-3775
