Ishiguro White Perforated Flange (Non-Gas Type) DA SOP-FF Type SS400 Equivalent 10K Nominal Size (A) 25 N10SOP-F-25A 1 pc

Catalog number: N10SOP-F-25A Features: ● JIS standard equivalent product. ● No need for troublesome plating removal work. ● The smooth welded surface can be finished beautifully even with an automatic welding machine. ● Zinc-specific gas during welding is also minimized. Applications: ● For piping under gentle conditions. Specifications: ● Nominal diameter A: 25 ● Nominal diameter B: 1 ● Inner diameter (mm): 34.5 ● Outer diameter (mm): 125 ● Thickness (mm): 14 ● Number of bolt holes (pcs): 4 ● Bolt hole diameter (mm): 19 ● Operating pressure (K): 10 ● Type: Slip-on ● Operating pressure: 10K Material/Finish: ● Steel (SS400 equivalent, zinc-plated finish)
