IMAO ID clamp MBID08 1 piece

Catalog number: MBID08 Features: ● Workpieces can be clamped from the inside. By self-cutting the clamping part, it can accommodate a wide range of workpiece diameters. Applications: ● For workpieces with multiple pieces. Specifications: ● Height (mm): 24.9 ● Clamping force (N): 11000 ● Thread dimensions: M8 x 1.25 ● Clamping diameter (mm): 20.0 ● Suitable workpiece diameter (mm): 13.5 to 20.0 ● Overall diameter (mm): 37.5 ● Allowable expansion diameter (mm): 0.3 ● Recommended expansion diameter when self-cutting (mm): 0.08 Material/Finish: ● Body: Steel (SUM24L) ● Tapered bolt: Steel (SCM440) Set contents/Accessories: ● 1 hexagonal nut ● 1 locking ring (MBID16C/MBID16D only)
