IMAO ID clamp MBID10 1 piece

Catalog number: MBID10 Features: ● Workpieces can be clamped from the inside. By self-cutting the clamping part, it can accommodate a wide range of workpiece diameters. Applications: ● For workpieces with multiple pieces. Specifications: ● Height (mm): 28.6 ● Clamping force (N): 20000 ● Thread dimensions: M10 x 1.50 ● Clamping diameter (mm): 27.0 ● Suitable workpiece diameter (mm): 18.0 to 27.0 ● Overall diameter (mm): 50.0 ● Allowable expansion diameter (mm): 0.35 ● Recommended expansion diameter when self-cutting (mm): 0.08 Material/Finish: ● Body: Steel (SUM24L) ● Tapered bolt: Steel (SCM440) Set contents/Accessories: ● 1 hexagonal nut ● 1 locking ring (MBID16C/MBID16D only)
