Eagle Claw Jack with lever rotation and safety valve Claw capacity 1.2t G-25 1 unit

Catalog number: G-25 Features: ● [Features] This hydraulic claw jack is equipped with "safety", "high work efficiency" and "durability". Since it can be lifted with either the claw or the head, it can be applied to a wider range of work than a normal hydraulic jack. ● [Features] It is possible to lift a heavy object of 1.2 tons from a low position of about 12 mm with human strength alone. ● [Safety] A safety valve circuit (relief valve) is standard equipment to prevent the jack from being damaged due to overload. ● [Workability] It is equipped with a swivel lever socket that rotates 180 degrees, so you can operate the pump from the side even in a narrow place with obstacles behind. ● [Workability] The attached operating lever is rigid and has a grip, so the pushing force is firmly transmitted to the jack. In addition, there is no need to worry about the connection coming loose because it has a two-piece locking mechanism. ● [Workability] It is designed to have a larger ram shaft (claw) lift per pump operation compared to a general hydraulic jack, making jacking work more efficient. ●[Workability] Operating force is the force required to push in the lever when the jack is loaded with a nominal load. The lever operating force of the EAGLE jack is 19kgf, which is about 45% less than the JIS standard of "35kgf or less." It requires less operating force than a typical hydraulic jack, allowing for relaxed work. ●[Durability] Through years of research into claw jacks, we have pursued durability when using the claws. In the "claw nominal load full-stroke repeated test" conducted under our own strict standards, we have achieved the highest level of performance evaluation in the industry. Uses: ●[Disaster prevention] This product is also used as disaster prevention equipment for saving lives. Specifications: ●Lifting force (kN) claw part: 12 (1.2) ●Lifting force (kN) head part: 25 (2.5) ●Stroke (mm): 100 ●Body height (mm): 203-303 ●Claw width (mm): 65 ●Claw length (mm): 50 ●Maximum claw height (mm): 112 ●Minimum claw height (mm): 12 ●Height (mm): 203-303 ●Claw length x claw width (mm): 50 x 65 ●Body dimensions (mm) Height: 203-303 ●Standard claw type Set contents/accessories: ●Handle
