Eagle Feed Type Claw Jack F-100TL 5t F-100TL 1 unit

Catalogue number: F-100TL Features: * A feed table is attached to the claw jack, making vertical and front-to-back positioning more efficient. * It slides smoothly within a range of 100 mm, allowing horizontal movement after lifting. * Push and return are achieved with a screw mechanism using a ratchet handle, allowing fine adjustments. * The handle is rotatable. * The slide table is integrated with the jack via a dovetail guide to prevent it from wobbling left and right. Specifications: ●Lifting force (kN) claw part: 50 (5.0) ●Lifting force (kN) head: Cannot be used ●Stroke (mm): 63 ●Body height (mm): 243-306 ●Claw width (mm): 75 ●Claw length (mm): 75 ●Maximum claw height (mm): 107 ●Minimum claw height (mm): 44 ●Width (mm): 75 ●Body dimensions (mm) Height: 243-306 ●Lever rotation ●With safety valve ●Feed table length x width: 443 x 223 mm Set contents/accessories: ●Handle ●Ratchet handle
