EBI EBI PLUG 10-50 BLACK (60 PACK) EP1050 1 PK

Catalogue number: EP1050 Features: ● Stepped tip makes it easy to insert into pilot holes. ● Color-coded by nominal diameter for easy identification. ● The lead angle at the center of the head guides the screw straight. ● The unique anti-rotation design firmly secures the attached equipment. Applications: ● For concrete and ALC. ● Color-coded by nominal diameter for easy identification. ● The lead angle at the center of the head guides the screw straight. ● The unique anti-rotation design firmly secures the attached equipment. ●An anchor plug made of environmentally friendly dioxin-free resin material. Specifications: ●Nominal diameter (mm): 10 ●Length (mm): 50 ●Drilling depth (mm): 60-65 ●Maximum tensile load (kN): 10.1 ●Maximum tensile load (kN) concrete: 10.1 ●Maximum tensile load (kN) ALC: 1.7 ●Pilot hole diameter (mm): 10 ●Pilot hole diameter (mm) concrete: 10 ●Pilot hole diameter (mm) ALC: 9.5 ●Compatible screws (mm): 5.8-6.8 ●Outer diameter (mm): 10 ●Color: Black ●Total length (mm): 50 ●Color: Black ●Compatible screws: Wood screws, tapping screws ●Pack ●Quantity (pieces): 60 Material/Finish: ●Polypropylene (PP) Caution: ●The maximum tensile load is the value when the concrete strength is Fc23.5N/m［［Ｍ２］］. ●Avoid using on ceilings. ●The maximum pull-out load is greatly affected by the material and condition of the base material. Please use a sufficient safety factor taking into consideration the construction conditions. ●Screw length = plug length + thickness of attachment●Before starting work, be sure to read the instruction manual carefully and fully understand it before using the product.
