EBI EBI PLUG 6-25 YELLOW (200 pcs) EP625 1 PK

Catalogue number: EP625 Features: ● Stepped tip makes it easy to insert into pilot holes. ● Color-coded by nominal diameter for easy identification. ● The lead angle at the center of the head guides the screw straight. ● Unique anti-rotation design firmly secures the attached equipment. Applications: ● For concrete and ALC. ● Color-coded by nominal diameter for easy identification. ● The lead angle at the center of the head guides the screw straight. ● Unique anti-rotation design firmly secures the attached equipment. ●An environmentally friendly resin anchor plug made of dioxin-free material. Specifications: ●Nominal diameter (mm): 6 ●Length (mm): 25 ●Drilling depth (mm): 35-40 ●Maximum tensile load (kN): 3.7 ●Maximum tensile load (kN) concrete: 3.7 ●Maximum tensile load (kN) ALC: 0.6 ●Pilot hole diameter (mm): 6 ●Pilot hole diameter (mm) concrete: 6 ●Pilot hole diameter (mm) ALC: 5.5 ●Compatible screws (mm): 3.1-4.1 ●Outer diameter (mm): 6 ●Color: Yellow ●Total length (mm): 25 ●Color: Yellow ●Compatible screws: Wood screws, tapping screws ●Pack ●Quantity (pieces): 200 Material/Finish: ●Polypropylene (PP) Caution: ●The maximum tensile load is the value when the concrete strength is Fc23.5N/m［［Ｍ２］］. ●Do not use on ceilings. ●The maximum pull-out load is greatly affected by the material and condition of the base material. Please use a sufficient safety factor taking into consideration the construction conditions. ●Screw length = plug length + thickness of object to be attached ●Before starting work, be sure to read the instruction manual carefully and fully understand it before using the product.
