Catalog number: EP825 Features: ● Stepped tip makes it easy to insert into pilot holes. ● Color-coded by nominal diameter for easy understanding. ● Lead angle at the center of the head guides the screw straight. ● Unique anti-rotation design firmly secures the mounting equipment. Applications: ● For concrete and ALC. Specifications: ●Nominal diameter (mm): 8 ●Length (mm): 25 ●Drilling depth (mm): 35-40 ●Maximum tensile load (kN): 4.8 ●Maximum tensile load (kN) concrete: 4.8 ●Maximum tensile load (kN) ALC: 1.0 ●Pre-drilled hole diameter (mm): 8 ●Pre-drilled hole diameter (mm) concrete: 8 ●Pre-drilled hole diameter (mm) ALC: 7.5 ●Compatible screws (mm): 4.8-5.8 ●Color: Blue ●Color: Blue ●Compatible screws: wood screws, tapping screws ●Packed Material/Finish: ●Polypropylene (PP) Note: ●The maximum tensile load is the value when the concrete strength is Fc23.5N/m［［Ｍ２］］.
