Catalog number: SNP635 Features: ● Installation can be done with a hammer, and removal can be done with a single screwdriver. Applications: ● For ALC and concrete. Specifications: ● Outer diameter (mm): 5.8 ● Length (mm): 35 ● Maximum thickness of object to be attached (mm): 6 ● Drilling depth (mm): 40mm - thickness of object to be attached ● Maximum tensile load (kN): 1.57 ● Pilot hole diameter (mm): 6 ● Pilot hole diameter (mm) concrete: 6 ● Pilot hole diameter (mm) ALC: 5.8 ● Head shape: Slotted ● Head shape: Slotted ● Packed Material/Finish: ● Body: Nylon ● Screws: Stainless steel Note: ● Maximum tensile load is the value when the concrete strength is Fc24.5N/m［［Ｍ２］］.
