Catalog number: NAD4MP Features: ● Ebi nuts are blind fasteners that combine the functions of nuts and rivets. ● They can be easily attached from one side to thin materials and pipes that are difficult to tap, and plastic plates that cannot be welded. ● By using the dedicated Ebi brand nut nut, you can adjust the stroke appropriately according to the thickness of the crimped plate, resulting in a uniform finish. ● Stable nut strength is ensured and it can be firmly installed. ● Comes in a durable plastic case for easy storage. ● Comes in a small pack so you can purchase only the number you need when you need it. Applications: ● For attaching parts to steel plate parts and plastic parts (bumpers, etc.) of cars. ● For attaching parts to aluminum building materials such as exteriors. ● For attaching accessories to thin plates, connecting pipes and flat plates, leveling agricultural tools and equipment, etc. Specifications: ● Crimping plate thickness (mm): 1.0-2.0 ● Countersink diameter (mm): 6.1 ● Compatible screw: M4 x 0.7 ● Nut outer diameter (mm): 6 ● Total length (mm): 11.0 ● Flange thickness (mm): 0.8 ● Number of pieces per pack: 35 ● Head shape: Large flange ● Flange diameter (mm): 9.0 ● Torque strength (N・m): 4.9 ● Thread shear strength (kN): 4.0 ● Comes in eco pack ● Flat head Material/Finish: ● Aluminum (A5056) Caution: ● If used with soft materials or thin base materials, the strength stated in the catalog may not be achieved.
