Catalog number: NAK5MP Features: ● Ebi nuts are blind fasteners that combine the functions of a nut and a rivet. ● They can be easily attached from one side to thin materials and pipes that are difficult to tap, and plastic plates that cannot be welded. ● By using the dedicated Ebi brand nut nut, you can adjust the stroke appropriately according to the thickness of the crimped plate, resulting in a uniform finish. ● The flange (brim) is small and thin, so the nut mounting part (flange) does not protrude from the base material surface, making it easy to install. ● Comes in a durable plastic case for easy storage. ● Stable nut strength is ensured and it can be installed firmly. ● Comes in a small pack so you can purchase only the number you need when you need it. Applications: ● For attaching parts to steel plate parts and plastic parts (bumpers, etc.) of cars. ● For attaching parts to aluminum building materials such as exteriors. ● For attaching accessories to thin plates, connecting pipes and flat plates, leveling agricultural tools and equipment, etc. Specifications: ● Crimping plate thickness (mm): 1.0-3.2 ● Pilot hole diameter (mm): 7.1 ● Compatible screw: M5 x 0.8 ● Nut outer diameter (mm): 7 ● Total length (mm): 12.5 ● Flange thickness (mm): 0.5 ● Pack quantity (pcs): 30 ● Head shape: Small flange ● Flange diameter (mm): 8.0 ● Torque strength (N・m): 7.8 ● Thread shear strength (kN): 6.4 ● Eco pack included ● Thin head Material/Finish: ● Aluminum (A5056) Caution: ● If used with soft materials or thin base materials, the strength listed in the catalog may not be achieved. ● Please be sure to read the instruction manual for the Linutter you are using carefully before starting work. ● Dimensions and weight are nominal values, so there may be some variation in the values.
