Catalog number: NSA48MP Features: ● Small size that can be used for necessary work without waste. ● Multiple base materials can be fastened from one side with one action. Specifications: ● Crimping plate thickness (mm): 9.5-12.7 ● Rivet length (mm): 16.7 ● Flange diameter (mm): 6.4 ● Rivet diameter (mm): 3.2 ● Pilot hole diameter (mm): 3.3-3.4 ● Shear strength (N): 960 ● Tensile strength (N): 1350 ● Eco pack included ● RoHS directive compliant ● Pack quantity (pieces): 55 ● Body material: Aluminum (A5154) ● Mandrel material: Steel (carbon steel) Material/Finish: ● Body: Aluminum (A5154) Caution: ● Please observe our specified dimensions for the appropriate crimping plate thickness and pilot hole diameter and take into consideration the safety factor when installing.
