Catalog number: NSA65CMP Features: ● Small size that can be used for necessary work without waste. ● Multiple base materials can be fastened from one side with one action. Specifications: ● Crimping plate thickness (mm): 4.8-8.0 ● Rivet length (mm): 13.1 ● Flange diameter (mm): 9.6 ● Rivet diameter (mm): 4.8 ● Pilot hole diameter (mm): 4.9-5.0 ● Shear strength (N): 2600 ● Tensile strength (N): 3900 ● Eco pack included ● RoHS directive compliant ● Pack quantity (pieces): 25 ● Body material: Aluminum (A5056) ● Mandrel material: Steel (carbon steel) Material/Finish: ● Body: Aluminum (A5056) Caution: ● Please observe our specified dimensions for the appropriate crimping plate thickness and pilot hole diameter and take into consideration the safety factor when installing.
