Catalog number: NSA56KMP Features: ● Small size that can be used for necessary work without waste. ● Multiple base materials can be fastened from one side with one action. Specifications: ● Crimping plate thickness (mm): 6.4-9.5 ● Rivet length (mm): 13.9 ● Flange diameter (mm): 8.0 ● Rivet diameter (mm): 4.0 ● Pilot hole diameter (mm): 4.1-4.2 ● Shear strength (N): 1550 ● Tensile strength (N): 2100 ● Eco pack included ● RoHS directive compliant ● Pack quantity (pieces): 45 ● Body material: Aluminum (A5154) ● Mandrel material: Steel (carbon steel) Material / Finish: ● Body: Aluminum (A5154) Caution: ● Please observe the appropriate crimping plate thickness and pilot hole diameter specified by our company and take into consideration the safety factor when installing.
