Catalog number: AP68EB Features: ● AP rivets have a wide range of suitable crimping plate thicknesses, so one type can be used to crimp a wide range of plates. ● Excellent airtightness, and can also be used with soft boards. Applications: ● Fastening metal to metal, fastening plastic to plastic, and fastening dissimilar base materials (metal to plastic, etc.). Specifications: ● Crimping plate thickness (mm): 6.4-12.7 ● Rivet length (mm): 18.5 ● Flange diameter (mm): 9.6 ● Rivet diameter (mm): 4.8 ● Pilot hole diameter (mm): 5.0-5.1 ● Shear strength (N): 1680 ● Tensile strength (N): 2380 ● Eco box included ● Eco box included Material/Finish: ● Rivet body (flange): Aluminum (A5052) ● Mandrel (shaft): Steel (carbon steel) Caution: ● Please observe our specified dimensions for the suitable crimping plate thickness and pilot hole diameter, and take into consideration the safety factor when installing. ●Please read the instruction manual for the riveter you are going to use carefully before starting work. ●The dimensions and weight are nominal values and may vary slightly.
