Onda Manufacturing Co., Ltd. Brass Ball Valve FF2 Type (Full Bore Compact) Rc2 x Rc2 Green T Handle FF2-T50 1 pc

Catalog number: FF2-T50 Features: ● Compact design with short face-to-face dimensions allows for space-saving piping. ● Thick wall design allows for maximum allowable pressure of 4.2MPa (600psi). ● Rc threads are Onda Seisakusho-specified dimensions, with a shallow reference diameter position and a short thread length. * R threads can be connected to the mating male thread. Applications: ● For hot and cold water, antifreeze, oil, air, and gas (non-flammable and non-toxic). Specifications: ●Nominal diameter A: 50 ●Nominal diameter B: Rc2 ●Total length (mm): 105 ●Height (mm): 73 ●Handle length D (mm): 110 ●Maximum allowable pressure (MPa): 4.2 (-15℃ to 70℃), 0.5 (up to 150℃) ●Operating temperature range (℃): -15 to 150 ●Compatible fluids: cold and hot water, antifreeze, oil, air, gas (non-flammable and non-toxic) ●Face to face (mm): 105 ●Inner diameter (mm): 50 ●Connection: Rc thread x Rc thread ●Allowable pressure: 4.2MPa (-15 to 70℃), 0.5MPa (below 150℃) ●Full bore compact type Material/Finish: ●Body: Brass
