Catalog number: AT-BTR5 Features: ● Adds Bluetooth functionality to car navigation systems/car audio systems. Connect a cable to the external input of the head unit to wirelessly control your smartphone or tablet. ● Adopts a multi-sound hole structure to improve the quality of the call function. ● Fast charge your smartphone or tablet with a USB port with a maximum total output of 3.4A (2.4A/1.0A). ● Wireless playback possible while charging your smartphone or tablet. ● Separate type that can be installed in various locations. ● Built-in amplifier volume for high-quality sound for various content. ● Compatible with Siri/Google Assistant Specifications: ● Color: Black ● Connection terminal: Cigarette lighter ● Frequency (Hz): 2.4 GHz band (2.402 to 2,480 GHz) ● Microphone: Type electret condenser type Directivity Omnidirectional Sensitivity -36 dB (1 V/Pa at 1 kHz) Frequency range 50 to 4000 Hz ● Power supply DC12V/24V ● Maximum output current 2.4A/1.0A Total 3.4A ● Audio output terminal φ3.5mm Audio output terminal ● Communication method Bluetooth standard Ver.5.0 compliant ● Maximum communication distance Within 10m in a clear line of sight ● Frequency band used 2.4GHz band (2.402GHz to 2.480GHz) ● Modulation method FHSS ● Compatible Bluetooth ● Profile A2DP, AVRCP, HFP ● Compatible codec SBC Material / Finish: ● ABS resin Set contents / Accessories: ● Main unit ● Accessories ● Fixing hook
