Catalogue number: SL-150-M10 Features: ●Can be locked at the desired point without the need for tools. ●Can be used for normal vertical hanging as well as horizontal hanging with the same load capacity. Applications: ●For lifting heavy objects. Specifications: ●Basic load capacity (t): 0.5 ●Bolt size: M10 ●B (mm): 28 ●Dimension (mm) A: 8.5 ●Dimension (mm) B: 28.0 ●Dimension (mm) C: 35.5 ●Dimension (mm) G: 14.7 ●Dimension (mm) H: 53.0 ●Dimension (mm) L: 27.8 ●Thread diameter: M10 ●Pitch (mm): 1.5 Material/Finish: ●Alloy steel
