K.F.C. Safety Anchor Stainless Steel SKB665 100 Pieces

Catalog number: SKB665 Features: ●An anchor system with double safety measures of "loosening prevention" and "nut drop prevention". ●In the unlikely event of loosening, the step on the anchor thread will stop the nut from falling off. Applications: ●For concrete. For installation in architecture, electricity, piping, signs, handrails, chairs, etc. Specifications: ●Screw size: M6 ●Total length (mm): 65 ●Sleeve length (mm): 30 ●Maximum tensile load (kN): 10 ●Embedding depth (mm): 33 ●Outer diameter (mm): 9.5 ●Pilot hole diameter (mm): 9.5 ●Drill diameter (mm): 9.5 ●Thickness of object to be attached (mm): 10 ●Special driving rod: SB-6 ●End screw length (mm): 3 ●Boxed ●Special driving rod: SB-6 Material/Finish: ●Stainless steel Note: ●The maximum tensile load is the value when the concrete strength is Fc18N/m［［Ｍ２］］.
