Catalog number: FCS-4032P Features: ●Ideal for fastening various components to concrete substrates, and attaching lightweight items such as pipe saddles. ●No need for plugs, excellent holding power, stainless steel SUS410 is used. Applications: ●For attaching pipe saddles, guide plates, etc. to concrete substrates. Specifications: ●Nominal diameter d (mm): 4.2 ●Counterbore diameter (mm): 3.4-3.5 ●Embedded depth (mm): *30 recommended ●Maximum tensile load (kN): *1.3 ●Drilling depth (mm): Embedded depth + 10 mm ●Length (mm): 32 ●Compatible driver: NO.2 ●TL (mm): 28 ●SL (mm): 4 ●Thread pitch (mm): 1.4 (18 threads) ●D (head diameter) (mm): 7 ●t (head height) (mm): 2.4 ●Concrete screw/plugless anchor ●Slotted head ●Sharp point ●High and low threads Material/Finish: ●Stainless steel (SUS410) ●Surface treatment: Passivated Caution: ●*The embedded depth will vary depending on the thickness and weight of the object to be attached, the strength of the concrete, etc., so please use according to the application. *The pull-out strength test is performed by embedding the screw 25mm into the test material: concrete compressive strength of 34.4N/mm (squared) conforming to JIS A1132. *The above pull-out strength value is the average value of actual measurements in-house and is not a guaranteed value. *Caution: Please note that larger pilot holes will reduce the pull-out strength. *Caution: Please wear safety goggles and a helmet as cutting chips will fly during work.
