Sanko All Anchor SC Stainless Steel Thread Size M8 Total Length 50mm SC-850 50 Pieces

Catalog number: SC-850 Features: ● Installation is as simple as driving in the core rod, so you can tell when installation is complete at a glance. ● The body and threaded part have the same diameter, so you can drill a small hole in the concrete. ● Can be installed directly from above the object to be attached. ● Nut tightening type, so it can be removed. Applications: ● For construction work, civil engineering work, electrical work, mechanical equipment work, etc. ● For construction and equipment work where rust prevention is desired. Specifications: ● Screw size: M8 ● Total length (mm): 50 ● Screw length (mm): 20 ● Maximum thickness of object to be attached (mm): 5 ● Pilot hole diameter (mm): 8.5 ● Maximum tensile load (kN): 6.5 ● Embedded depth (mm): 35 ● Boxed Material/Finish: ● Stainless steel (SUS304 series) Note: ● Maximum tensile load is the value when the concrete strength Fc = 21N/[[MM2]].
