Sanko Techno Amera Hanger ITA Type Steel with Drill ITA-3010V+D 1 Box

Catalogue number: ITA-3010V+D Features: ●Double plate structure (= 2 sheets) provides strong holding power for clamping objects. ●The roll plate is shorter than the normal IT hanger type, so it can be installed easily even inside extruded cement boards. ●The roll plate is shorter for extruded cement boards, so it can be installed easily. ●ECP Association certified product. Applications: ●For extruded cement boards. ●For attaching handrails and distribution boards, etc. ●For hollow walls●For installing handrails, brackets, distribution boards, bulletin boards, etc. on hollow walls. Specifications: ●Screw size: W3/8●Total length (mm): 102●Screw length (mm): 73●Pilot hole diameter (mm): 15.0●Drill diameter (mm): 15.0●Plate length (mm): 30●Maximum tensile load (kN): 4.26●Test base material: Extruded cement board●Required hollow section (mm): 30●Clip thickness (mm): 17-73●Neck length (mm): 90●Length (mm): 102●Boxed●Includes 1 Amera drill Material/Finish: ●Steel●Surface treatment: Trivalent chromate treatment Set contents/Accessories: ●30 Amera hangers, 1 Amera drill (AMD-15.0X120)●Nut with seat Note: ●A hollow section longer than the plate length is required for installation. Please check the dimensions of the hollow section before use. ●When drilling holes, please use the Amera Drill, a special drill that will not damage the extruded cement board.
