Sanko Techno All Anchor SC Type Stainless Steel Metric Screw SC-860 50 Pieces

Catalog number: SC-860 Features: ● Installation is as simple as driving in the core rod, so you can tell at a glance when installation is complete. ● The body and threaded part have the same diameter, so you can drill a small hole in the concrete. ● Can be installed directly from above the object to be attached. ● Nut tightening type, so it can be removed. Applications: ● For construction work, civil engineering work, electrical work, mechanical equipment work, etc. ● For construction and equipment work where rust prevention is desired. Specifications: ● Screw size: M8 ● Total length (mm): 60 ● Screw length (mm): 20 ● Maximum thickness of object to be attached (mm): 15 ● Pilot hole diameter (mm): 8.5 ● Maximum tensile load (kN): 6.5 ● Embedded depth (mm): 35 ● Maximum shear load (kN): 10.6 ● Quantity (number in small box): 50 ● Boxed Material/Finish: ● Stainless steel (SUS304 series) Note: ● Maximum tensile load is the value when the concrete strength Fc = 21N/[[MM2]].
